5IK60RGN-CF + 5GN30KB 60W AC Variable Speed Gear Motor

The 5IK60RGN-CF is a compact 60W single-phase AC variable speed motor with a 90 × 90 mm frame and 220V input. When paired with a 5GN30KB gearhead and US-52 speed controller, it provides adjustable-speed, low-speed drive performance for conveyors, packaging machinery and industrial automation systems.

Low-Noise Gearbox

Variable Speed Control

3:1–500:1 Gear Ratios

IP44 Protection

Request a Quote Downloads & CAD

Overview

The 5IK60RGN-CF is designed for applications requiring adjustable motor speed in a compact 90 × 90 mm frame. When paired with a 5GN series gearhead and US-52 speed controller, it provides a speed control range of 90–1300 rpm at 50Hz and 90–1600 rpm at 60Hz.

Fixed-speed induction versions are also available, including the 5IK60GN-CF for single-phase 220V and the 5IK60GN-YF for three-phase 220V / 380V applications. Round-shaft versions include the 5IK60A-CF fixed-speed model, 5IK60RA-CF variable-speed model and 5IK60A-YF three-phase model.

Specifications

Model	5IK60RGN-CF
Output Power	60W
Voltage	220V
Frequency	50 / 60Hz
Speed Control Range	90–1300 rpm 50Hz / 90–1600 rpm 60Hz
Starting Torque	3.3 kg·cm
Allowable Torque	5.0 kg·cm 1200 rpm / 1.4 kg·cm 90 rpm
Rated Current	0.52A
Motor Type	Single-phase AC Variable Speed Motor

Gearbox & Performance

Gear Ratio	3	5	10	15	20	30	36	50	60	75	100	180
Output Speed 50Hz r/min	500	300	150	100	75	50	41	30	25	20	15	8.3
Output Speed 60Hz r/min	600	360	180	120	90	60	50	36	30	24	18	10
Allowable Torque kg·cm	11	17.8	33.8	55.4	72.5	105	105	147	147	147	147	147

Options: The 5IK60RGN-CF motor is compatible with 5GN series gearheads. Gear ratios from 3:1 to 500:1 are available. The 5GN30KB configuration shown on this page uses a 30:1 reduction ratio. Gearhead output shaft diameters of 12 mm and 15 mm are available.

60W Induction Motor Model Options

Model	Voltage	Current	Rated Speed	Starting Torque	Rated Torque	Capacitor
5IK60GN-CF	Single-phase 220V	0.52A	1300 rpm 50Hz / 1600 rpm 60Hz	3.97 kg·cm	4.5 kg·cm	4 μF / 450V
5IK60GN-YF	3-Phase 220V / 380V	0.40A / 0.23A	1300 rpm 50Hz / 1600 rpm 60Hz	9.7 kg·cm	4.5 kg·cm

Downloads & CAD

Download the 3D CAD model and dimension drawing for this AC gear motor.

3D CAD Model

Download 3D CAD

Dimension Drawing

Download Drawing

Applications

Conveyors

Labeling Machines

Packaging Machines

Industrial Automation

Selection & Support

Fixed-speed gear motor: 5IK60GN-CF + 5GN gearhead
Variable-speed gear motor: 5IK60RGN-CF + 5GN gearhead + US-52
3-Phase 220V / 380V: 5IK60GN-YF, VFD required for speed control
Gear ratios: 3:1–500:1
5GN gearhead & motor selection support

FAQ

The 5IK60RGN-CF is designed for variable-speed operation with a compatible speed controller, while the 5IK60GN-CF is a fixed-speed single-phase AC induction motor.

This model is suitable for replacement applications where the mounting dimensions, voltage, shaft configuration and gear ratio match the original motor. Please confirm the installation dimensions before ordering.

Yes. The 5IK60RGN-CF can be combined with different 5GN series gearheads with gear ratios from 3:1 to 500:1. Please provide your required output speed or gear ratio for model selection.

Yes. Round-shaft versions are available. The 5IK60A-CF is the fixed-speed single-phase model, the 5IK60RA-CF is the variable-speed single-phase model, and the 5IK60A-YF is the three-phase model.
