80YT25GV22 + 80GK36H 25W Single Phase Variable Speed AC Gear Motor

25W single phase variable speed AC motor with 80GK36H standard gearbox and 36:1 ratio. Built-in speed feedback enables closed-loop speed control for stable operation, with a speed range of 90–1400 r/min at 50Hz and 90–1600 r/min at 60Hz. Suitable for conveyors, packaging machinery and industrial automation.

Closed-Loop Speed Control

Low-Noise Gearbox

36:1 Gear Ratio

IP54 Protection

Request a Quote Downloads & CAD

Overview

The JSCC 80YT25GV22 is a 25W single phase variable speed AC motor with built-in speed feedback for closed-loop speed regulation. Paired with the 80GK36H standard gearbox at a 36:1 ratio, it provides reduced output speed and increased torque for compact industrial equipment. The motor supports smooth speed adjustment, fast stopping and 0–10V analog speed control when used with a compatible controller. Its compact 80 × 80 mm frame makes it suitable for conveyors, packaging machinery, food processing equipment and other industrial automation applications.

Specifications

Model	80YT25GV22
Output Power	25W
Voltage	220V
Frequency	50 / 60Hz
Poles	4
Speed Control Range	90–1400 r/min 50Hz / 90–1600 r/min 60Hz
Starting Torque	140 mN·m 50Hz / 120 mN·m 60Hz
Rated Current	0.22A 50Hz / 0.22A 60Hz
Insulation Class	Class H
Protection	IP54
Rated Time	Continuous
Motor Type	Single-phase AC Speed Control Motor

Gearbox & Performance

Gear Ratio	3	5	10	15	20	30	36	50	60	75	100	180
Output Speed 50Hz r/min	467	280	140	93	70	47	39	28	23	19	14	7.8
Allowable Torque 50Hz N·m	0.40	0.67	1.33	2.0	2.66	4.0	4.79	6.65	8	8	8	8
Output Speed 60Hz r/min	533	320	160	107	80	53	44	32	27	21	16	8.9
Allowable Torque 60Hz N·m	0.34	0.57	1.14	1.71	2.28	3.42	4.10	5.70	6.84	8	8	8

Options: The 80YT25GV22 motor is compatible with standard, intermediate, right-angle solid shaft and right-angle hollow shaft gearboxes. Standard gearbox ratios from 3:1 to 180:1 are available, and higher reduction ratios up to 1800:1 can be configured with an intermediate gearbox. Single-phase 110V and custom voltage options are available upon request.

Downloads & CAD

Download the 3D CAD model and dimension drawing for this AC gear motor.

3D CAD Model

Download 3D CAD

Dimension Drawing

Download Drawing

Applications

Conveyors

Packaging machinery for gear motor applications

Packaging Machines

Food Processing

Industrial robotic arm for automation applications

Industrial Automation

Selection & Service

Voltage options: 110V / 220V
0–10V analog speed control
Closed-loop speed control
Gear ratios: 3:1–1800:1
Multiple gearbox configurations
Motor selection & customization support

FAQ

Yes. The motor has built-in speed feedback and works with a compatible controller to maintain stable speed through closed-loop control.

Standard gearbox ratios from 3:1 to 180:1 are available. Higher reduction ratios up to 1800:1 can be configured with an intermediate gearbox depending on the application requirements.

Yes. Single-phase 110V and 220V versions are available, and custom voltage options can also be provided upon request.

The motor can be paired with standard, intermediate, right-angle solid shaft and right-angle hollow shaft gearboxes to suit different installation requirements.

Yes. The round shaft version is model 80YT25DV22. It is a 25W single phase variable speed AC motor without a gearbox and is suitable for direct coupling, custom machinery and applications using an external transmission system.
